Mirror Command in AutoCAD: A Comprehensive Guide

Mirroring objects is a fundamental operation in AutoCAD, allowing you to create symmetrical designs and duplicate objects with ease. The Mirror command offers a powerful way to manipulate objects about a specified axis or plane, and understanding its essential aspects can greatly enhance your AutoCAD skills.

Below is a comprehensive guide to using the Mirror command in AutoCAD, covering its key features, steps, and advanced options:

Key Features

The Mirror command provides several key features that make it a versatile tool for mirroring objects:

  • Multiple Objects Mirroring: You can mirror multiple objects simultaneously, saving time and ensuring consistency.
  • Axis and Plane Specification: Define the axis or plane about which the objects will be mirrored, giving you control over the symmetry.
  • Copy or Delete Mirrored Objects: Choose whether to create copies of the original objects or delete them after mirroring.

Step-by-Step Usage

To use the Mirror command, follow these steps:

  1. Select the objects you want to mirror.
  2. Type "Mirror" in the command line and press Enter.
  3. Specify the first point that defines the axis or plane of mirroring.
  4. Specify the second point to complete the axis or plane definition.
  5. Choose "Copy" or "Delete" to determine what happens to the original objects.

Advanced Options

The Mirror command offers several advanced options that provide greater control:

  • Mirror with Negative Scale: Flips the mirrored objects instead of creating a symmetrical copy.
  • Mirror About Center Point: Mirrors the objects about their center point, creating symmetrical reflections.
  • Use Reference Plane: Mirrors the objects onto a specified reference plane, allowing for complex mirroring operations.

By mastering these essential aspects of the Mirror command, you can effectively create symmetrical designs, duplicate objects with precision, and enhance your AutoCAD workflows.
